Our Machining Capabilities are State of the Art
Whether they are Fortune 500 companies requiring production runs in the thousands or small businesses and individuals needing a single prototype, our clients have found that Pro Engineering provides them with an outstanding partner in manufacturing.
Computer/Electronic File Resources
Our extensive selections of software and multi-platform systems allow us to read virtually any type of e-files.
Machines and associated equipment are supported by state of art CAD/CAM systems and our excellent workforce is fully qualified to meet any and all machining requirements.
Material Variety
Pro Engineering works with virtually all types of material, including aluminum, steel, stainless steel, brass, bronze, copper, plastic, super alloys and more.
Equipment list, some of our machine capabilities:
- Makino F5 5-Axis CNC Machining Center with Pro 5 Control - 20,000 HSK63 SPINDLE (+)
- YCM GT250A CNC Turning Center
Fanuc Enhanced MXP1001 CNC Controler
8" 3 Jaw Hydraulic Chuck
2.05" Bar Capacity- Four YCM FX380A-5AX 5 AXIS MACHINING CENTER with FANUC 31i-B5 CONTROL
380MM TILT TRUNION ROTARY TABLE
30 H.P. MAIN SPINDLE MOTOR
12,000 RPM MAX SPINDLE SPEED- Four YCM CX4 5-Axis Machining Center with FANUC 31i-B5 Control
Travels 25.6″ X 20.47″ X 18.9″
Travels A-axis 150˚ (+30˚/ -120˚) C-axis 360˚
Table ø13.8″
Max. Workpiece Dimensions ø15.8″x12.2″
12,000 rpm IDD Spindle (Opt 15,000 rpm)
30HP, BBT-40 Taper, Dual Contact- STAR SB-20E Swiss Type Automatic Lathe - Fanuc 0i-TD CNC control unit, 7 axes, Ø 20mm max. machining diameter. (+)
- STAR SR-20JII Swiss Type Automatic Lathe – Fanuc 32i-B control unit, 7 axes, Ø20mm max machining diameter
- Two Fanuc Robocut Wire EDM - precision wire Electric Discharge Machining (EDM) / Axes: 23.6"x15.7"x12.2", Air Jet AWF II, High Precision Cutting
- Two Makino a51 - Horizontal Machining Centers / 4 axis, Pallet:15.7" X: 22.0" Y: 22.0" Z: 23.6", Spindle RPM: 14,000, Rapid Traverse: 2,360 in/min, Cutting Feedrate: 1,968 in/min, Maximum Workpiece: ø24.8" x 35.4", Tool to Tool: 0.9 secs, Chip to Chip: 2.2 secs
- YCM NXV1680A VERTICAL MACHINING CENTER
FANUC ENHANCED MXP 200FA WITH 200 BLOCK LOOK AHEAD
64.2"X30.0"X27.6"(XYZ TRAVELS)
12,000 RPM MAXIMUM SPINDLE SPEED AICC CONTOUR CONTROL- YCM JC6 CNC MACHINING CENTER WITH FANUC PLUS CONTROL
POWERFULL 25 HP IDD SPNDLE
12,000 RPM MAX SPINDLE SPEED
23.6”X16”X17.7’’ XYZ TRAVELS- YCM E5
Axis Travels (XYZ): 40" x 20.5" x 21.2"
10,000 RPM Spindle Speed
Spindle Power: 20 HP- FEELER-VMX-1020
AXIS TRAVEL (XYZ) 40’’x20.5’’x22’’
12,000 RMP SPINDLE SPEED
30HP SPINDLE DRIVE MOTOR
- Akira-Seiki Performa V2, CNC, 25X18-20
- Akira-Seiki sl25, CNC Lathe, Fanuc series O-T control, 22" swing over bed, 12" turning diameter, 20hp, 4500 RPM spindle, repeatability 0.0001".
- Three YCM XV Series, 560A - spindle speed 45~10,000rpm; spindle power 5.5/7.5/11kW; spindle taper BT40; XYZ travel 22"x16.1"x17.7"; table size 27.6"x16.5"; rapid feed rate XYZ 1260/1260/945ipm; accuracy (linear) table positioning A 0.00039"; repeatability R 0.00028"; tool magazine capacity 20
- Three YCM XV 1250A Series, High Performance Vertical Machining Center, spindle speed 45~10,000rpm, X-axis: 50", Y: 20.5", Z :21.3" - state-of-the-art technology, exceptional accuracy
- Precision toolroom lathe Hardinge 6" x 14", Repeatability 0.0002
- YCM TC Series 36W, CNC Lathe Machining Center, 22" Max Dia of manufacturing parts
- Alliant, Manual Mill, 30" x 20" X-Y
- Birmingham manual lathe, model 1440 (that is also the size of the lathe, 14"x40" y-x), repeatability 0.001".
- Astro vertical mill, 30"x20" x-y, repeatability 0.001".
- DoAll Mdl.2013-U 20" Vertical Band Saw.
- DoAll C-916 Horizontal Band Saw.
- Hydraulic Press Model 5220, Heavy Duty Hydraulic Shop Press 20 Ton
- Clark Forklift, 7000LB
- Cyklon Blasting System, Sand Bead Blaster
- Miscellaneous: Grinders, Drillpresses, Rotary Tables, Indexing Heads, etc.
We also have comprehensive proficiency of secondary processes and frequently collaborate with approved vendors to develop their capabilities in order to meet our customers’ requirements.
You'll be impressed by what we can do for you - the work you need at an exceptionally reasonable price.
